Tape and Reel Spheres

Tape and Reel Solder Spheres

Tape and reel solder spheres are used for automated BGA ball attach, pick-and-place systems, and high-volume SMT production. EasySpheres supplies solder spheres in tape and reel packaging in Sn10Pb90, Sn63Pb37, and SAC305, in diameters from 0.300 mm to 0.760 mm, on EIA-481-compatible 13-inch reels, helping electronics manufacturers and EMS providers improve handling efficiency and placement consistency.

Specifications

  • Alloys and diameters: Sn10Pb90, Sn63Pb37, and SAC305, in sphere diameters from 0.300 mm to 0.760 mm; contact EasySpheres for special requirements
  • Applications: Automated PCB assembly, BGA ball attach, pick-and-place systems, SMT production
  • Carrier tape and reel: Polycarbonate carrier tape compatible with EIA-481-E, 8 mm, supplied on 13-inch reels, standard 20,000 spheres per reel
  • ESD: Static-dissipative carrier tape, surface resistivity 10^4 to 10^8 ohms per square
  • Quality: Alloy purity in conformance with IPC J-STD-006; Certificate of Conformance ships with every order; standard quality documentation available on request.
  • Compliance: RoHS status depends on the alloy: SAC305 is RoHS-compliant; Sn63Pb37 and Sn10Pb90 are leaded and not RoHS-compliant as supplied (Sn10Pb90 may qualify under Annex III exemption 7(a); customer confirms).
  • Shelf life: Two years from the date of shipment from the EasySpheres facility (product held sealed in controlled inert storage until shipped).
  • Industries: EMS, PCB assembly, high-volume electronics manufacturing

Selecting Tape-and-Reel Solder Spheres for BGA Ball Attach

When selecting tape-and-reel solder spheres for BGA ball attach, consider the required alloy, sphere diameter, and compatibility with your pick-and-place equipment. Confirm that the available product specifications meet your application requirements before ordering.

  • Alloy selection: Choose from Sn10Pb90, Sn63Pb37, and SAC305 based on your application requirements.
  • Sphere diameter: Available diameters range from 0.300 mm to 0.760 mm.
  • Equipment compatibility: Check carrier tape compatibility and confirm suitability for your specific pick-and-place feeder.
  • Order quantity: The minimum order is one reel, with 20,000 spheres per standard reel.

Frequently Asked Questions

Is EasySpheres tape-and-reel packaging compatible with pick-and-place equipment?

EasySpheres supplies solder spheres in 8 mm polycarbonate carrier tape compatible with EIA-481-E. The tape-and-reel format supports consistent feeding for automated BGA ball attach. Confirm compatibility with your specific feeder before ordering.

What is the minimum order quantity for tape-and-reel solder spheres?

The minimum order quantity is one reel. Each standard 13-inch reel contains 20,000 solder spheres. Tape-and-reel options are available in Sn10Pb90, Sn63Pb37, and SAC305 alloys.

How do I choose the right solder sphere diameter for BGA ball attach?

EasySpheres offers tape-and-reel solder spheres in diameters from 0.300 mm to 0.760 mm. The appropriate diameter depends on your BGA component and application specifications. Verify the required diameter before placing an order.

What is the difference between taped and bulk solder spheres?

Taped solder spheres are supplied in carrier tape on reels for automated handling and placement, while bulk solder spheres are supplied in bulk packaging. The right option depends on your assembly process and equipment requirements. Learn more about the differences in our guide to bulk and taped solder spheres.

!
